| G.652 | G.655 | 50/125 µm | 62,5/125µm | ||
| Dämpfung (+20°C) |
850nm | ≤3,0 dB/km | ≤3,0 dB/km | ||
| 1300nm | ≤1,0 dB/km | ≤1,0 dB/km | |||
| 1310nm | ≤0,36 dB/km | ≤0,40 dB/km | |||
| 1550nm | ≤0,22 dB/km | ≤0,23 dB/km | |||
| Bandbreite (Klasse A) | 850nm | ≥500 MHz·km | ≥500 MHz·km | ||
| 1300nm | ≥1000 MHz·km | ≥600 MHz·km | |||
| Numerische Apertur | 0,200 ± 0,015 NA | 0,275 ± 0,015 NA | |||
| Kabel- Grenzwellenlänge |
≤1260 nm | ≤1480 nm | |||
| Kabelart | Faseranzahl | Bündeladeranzahl T _ |
Füllstoffzahl s |
Kabeldurchmesser mm |
Kabelgewicht kg/km |
Zugfestigkeit Langfristig/kurzfristig N |
Druckfestigkeit lang/kurz N/100 m |
Biegeradius Statisch/dynamisch mm |
| GYTY53-2~6 | 2-6 | 1 | 4 | 12.5 | 160 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-8~12 | 8-12 | 2 | 3 | 12.5 | 160 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-14~18 | 14-1 | 3 | 2 | 12.5 | 160 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-20~24 | 20-2 | 4 | 1 | 12.5 | 160 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-26~30 | 26-3 | 5 | 0 | 12.5 | 160 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-32~36 | 32-3 | 5 | 0 | 12.5 | 160 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-38~48 | 38-4 | 5 | 0 | 12.5 | 160 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-50~60 | 50-6 | 5 | 0 | 12.5 | 160 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-62~72 | 62-72 | 6 | 0 | 13.2 | 200 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-74~8 | 74-8 | 7 | 1 | 15.0 | 240 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-86~96 | 86-9 | 8 | 0 | 15.0 | 240 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-98~108 | 98-108 | 9 | 1 | 16.0 | 280 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-110~120 | 110-120 | 10 | 0 | 16.0 | 280 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-122~132 | 122-1 | 11 | 1 | 18.0 | 290 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-130~144 | 134-1 | 12 | 0 | 18.0 | 290 | 1000/3 | 1000/3 | 15D/30D |
| GYTY53-146~216 | 134-1 | 18 | 0 | 18.0 | 290 | 1000/3 | 1000/3 | 15D/30D |
